Wallbox Pulsar Max 7.4KW

Full Installation Walkthrough

This installation in Ingleby Barwick features the Wallbox Pulsar Max 7.4KW, one of the most popular smart EV chargers on the UK market, and this video includes a detailed comparison with the MyEnergi Zappi to help homeowners decide which charger is right for their specific needs.

The Wallbox Pulsar Max is a compact, beautifully designed charger that packs impressive smart features into a surprisingly small unit. It is one of the smallest EV chargers available, measuring roughly the same size as a hardback book, which makes it an excellent choice for properties where aesthetics are a priority or where wall space is limited. Despite its small size, it delivers the full 7.4KW single-phase charging rate that is standard for UK home installations.

The installation at this Ingleby Barwick property was straightforward. The detached house had a modern consumer unit with spare ways available, and the cable run from the board to the proposed charger location on the front wall was approximately eight metres. We installed a dedicated radial circuit using 6mm twin and earth cable, protected by a Type A RCBO in the consumer unit as specified by the Wallbox installation requirements.

The Pulsar Max was mounted at the agreed height on the front wall, positioned to allow easy access to the charging cable from both sides of the driveway. The unit was fixed to the masonry wall using the supplied bracket, and the cable entry was made from below through a weatherproof gland. The installation took less than half a day from start to finish, including testing and commissioning.

The Wallbox app was set up on the homeowners phone during the handover, and we walked them through the key features including scheduled charging, power adjustment, real-time monitoring and the ability to set a maximum monthly energy budget for vehicle charging. The Pulsar Max connects to the home Wi-Fi network and all management is done through the cloud-based app, which also provides historical charging data and cost tracking.

Now for the comparison with the MyEnergi Zappi, which is the other charger we most frequently install. Both are excellent products, but they suit different households depending on their priorities and existing or planned energy systems.

The Zappi's standout feature is its solar integration capability. If you have solar panels or plan to install them in the future, the Zappi's ECO and ECO+ modes allow it to automatically use surplus solar generation to charge your vehicle, potentially reducing your charging costs to zero during sunny months. The Zappi achieves this through a CT clamp that monitors the grid connection and adjusts the charging rate in real time to match the available solar surplus. The Wallbox Pulsar Max does not have this built-in solar diversion capability, although it can be integrated with some third-party energy management systems for basic solar awareness.

In terms of build quality and design, the Wallbox Pulsar Max has a slight edge in aesthetics. Its compact, circular design with a glowing LED ring is genuinely attractive and looks premium on any wall. The Zappi is larger and more utilitarian in appearance, although its robust construction and weather resistance are excellent. Both chargers are built to withstand UK weather conditions and carry appropriate IP ratings for outdoor installation.

The Wallbox app is generally considered more polished and intuitive than the MyEnergi app, with a cleaner interface and more straightforward navigation. However, the MyEnergi app provides more detailed energy data, particularly when used in conjunction with other MyEnergi products like the Eddi hot water diverter and the Libbi battery.

For charging speed, both units deliver the same 7.4KW rate on a single-phase supply, so there is no difference in how quickly your vehicle will charge. A typical EV with a 60kWh battery will add roughly thirty miles of range per hour of charging at this rate, which means an overnight charge from midnight to seven in the morning will add over two hundred miles of range.

Our recommendation is straightforward: if you have solar panels or plan to get them, choose the Zappi for its unmatched solar integration. If you do not have solar and are not planning to install it, the Wallbox Pulsar Max offers a sleek, smart and reliable charging experience at a competitive price point. Both chargers are OZEV approved for the government grant, both are compatible with all electric vehicles, and both are products we are happy to install and stand behind.

This Ingleby Barwick homeowner chose the Pulsar Max because they do not currently have solar panels and were primarily attracted by the compact design and the excellent app experience. The charger has been performing flawlessly since installation, and the homeowner reports that it has transformed their EV ownership experience compared to the granny charger they were previously using, cutting their charging time by more than seventy percent.
